2025 TYM T474CH

2025 TYM T474CH Hydro. CALL FOR DISCOUNTS!!

Vehicle Details
Year: 2025
Make: TYM
Model: T474HC TL IND
Color: Red
Condition: New

Options Added
Hydrostatic Transmission
Front End Loader
Factory Cab
Industrial Tires
Warranty (see below)

Loader Specifications
Maximum Lift Height to Pivot Pin: 105
Maximum Lift Height Under Lever Bucket: 96.5
Clearance w/ Bucket Dumped: 80.4
Reach at Maximum Lift Height: 16.5
Maximum Dump Angle: 45 Degrees
Reach w/ Bucket on Ground: 69.2 Degrees
Maximum Rollback Angle: 38 Degrees
Digging Depth: 6.9
Overall Height in Carry Position: 46.7
Depth of Attachment: 19.4
Height of attachment: 21.9
Length of Attachment: 25.5
Loader Total Weight: 1,021 lbs.
Weight of Boom & Quick Attach: 514 lbs.
Weight of Mounting Frame: 278 lbs.
Weight of Bucket: 229 lbs.
Lift Capacity to Maximum Height: 2,152 lbs.
Breakout Force at Ground Level: 3,198 lbs.
Bucket Rollback Force at Ground Line: 3,012 lbs.
Relief Valve Setting: 2,347 psi.
Rated Flow: 7.7 GPM.
Lift Cylinder: 2.2x 1.2
Bucket Cylinder: 2 x 1.2
Bucket Width: 66
Boom Raising Time: 5.4 Sec.
Boom Lowering Time: 3.8 Sec.
Bucket Rollback Time: 2.5 Sec.
Bucket Dumping Time: 4.0 Sec.

Industrial Tire Specifications
Front R4: 10x16.5 6PR
Rear R4: 43x26.00-20 4PR
Tire Weight: 602 lbs.

Engine
TYM A2300N2
4-Cylinder Diesel
48.3hp @2600 RPM
PTO 32.3 HP

Powertrain & Specs
Power Steering w/ Dual-Gear Pump
Wet Disc Brakes
Selectable Four Wheel Drive
Category I Three Point Hitch, 2,646 lbs Capacity
540 RPM Independent PTO
9 Gallon Fuel Capacity
70A Alternator, 12V System

Weights
Tractor: 3,607lbs
Loader: 1,020.7lbs
Total Weight: 4,627.7lbs
Liquid Ballast (optional): 836lbs
Total Weight with Ballast: 5,463.7lbs
