FASTTRAC 8.5' WIDE
VALUE DRIVEN WITH A SPIRIT THAT'S BORN TO HAUL!
The FastTrac® 8.5' Wide brings a whole new level of value to the light-duty recreational hauler. A balanced combination of versatility and affordability, the FastTrac® 8.5' Wide delivers on all fronts. From its unpretentious styling to its uncompromising safety, only Wells Cargo® could pack so much value into an entry-level trailer. No other cargo trailer in its class offers attributes like a bull nose profile, rugged steel frame, platform lowering drop axles, 16" starbright stoneguard, and 3/4" PlexCoreTM high performance interior flooring. There's no doubt about it, the FastTrac® 8.5' Wide is a quick study in getting more bang for your buck!
Model shown features the popular Deluxe Package that includes .030 Exterior Metal, 3/8" PlexCore High Performance SIdewalls, and 5000 lb. Floor D-Rings.
FEATURES
1,000 lb. Surface Wall Mounted Rope-Ring (4)
Exclusive Bull Nose Profile
12v LED Slim Line Tail Lights
Entire Chassis Undercoated
E-Z Lube® Hubs
1-Piece Aluminum Roof
12v LED Exterior Lighting
16" OC Vertical Posts3/4" PlexCore High-Performance Interior Decking
32" Side Entry Door with Bar LockRear Ramp Door with Spring Assist16" Starbright StoneguardElectric Brakes with Breakaway KitFlow-Thru Sidewall Vents
Smooth Aluminum Fenderettes
16" OC Crossmembers16" Ramp Extension15" Radial Tires
Silver Spoke Wheels
White .024 Aluminum Exterior (with screws)
Economy Sidewall Liner
Spring Axles with 4" Drop2" x 6" Tube Main Rails24" OC Tube Roof Bows1-Year Limited Warranty500 lb. D-Ring Tie-Downs (4)
Standard Features, Specifications and Available Options subject to change without notice.
SPECIFICATIONS
MODEL FT8520T3-D
BODY LENGTH 21'6"
BODY WIDTH 8'4"
OVERALL LENGTH 23'8"
OVERALL WIDTH 8'6"
OVERALL HEIGHT 8'2"
INTERIOR LENGTH 21'3"
INTERIOR WIDTH 8'1"
INTERIOR HEIGHT 6'6"
WIDTH BETWEEN WHEEL WELLS 83"
PLATFORM HEIGHT 19"
AXLE QUANTITY Tandem
TOTAL AXLE CAPACITY 7,000 lbs.
BRAKES WITH BREAKAWAY KIT Electric Drum
RADIAL TIRE SIZE ST205/75R15
TIRE LOAD RANGE C
HITCH BALL SIZE 2-5/16"
HITCH HEIGHT TO TOP OF BALL 18"
HITCH WEIGHT (% OF CURB WEIGHT) 10% to 15%
CURB WEIGHT (APPROXIMATE) 3,060 lbs.
GVWR 7,000 lbs.
PAYLOAD CAPACITY (APPROXIMATE) 3,940 lbs. .
REAR RAMP DOOR OPENING (W x H) 94" x 72"
12v TRAILER END CONNECTOR 7-Way
Standard Features, Specifications and Available Options subject to change without notice.
