Specifications
ENGINE
ENGINE TYPE
Single cylinder, liquid cooled, 4-stroke, SOHC, 4-valve
DISPLACEMENT
580cc
MAX POWER
44 HP @ 6500 RPM
MAX TORQUE
37 LB-FT @ 6000 RPM
FUEL SYSTEM
EFI
COOLING SYSTEM
Liquid cooled
DRIVE
2WD/4WD/4WD lock
TRANSMISSION
CVTech® CVT P/R/N/H/L
CHARGING OUTPUT (Watts)
600W
DIMENSIONS & WEIGHT
LENGTH X WIDTH X HEIGHT
88” x 46.5” x 55”
WHEEL BASE
58.5”
DRY WEIGHT
863 lbs.
GROUND CLEARANCE
10.6”
FUEL TANK CAPACITY
4.75 gal.
RACK CAPACITY
Front 75 lbs. / Rear 100 lbs.
SEAT HEIGHT
21”
TURNING RADIUS
12.1'
CHASSIS
SUSPENSION
Front/Rear: Double A-arm independent
WHEELS
12” Cast Aluminum
TIRES
Front: 26” x 9” x 12” / Rear: 26” x 11” x 12”
SHOCKS
Spring preload adjustable, oil damped
BRAKES
4-wheel hydraulic disc with parking brake
WHEEL TRAVEL
Front 6.3” / Rear 8.3”
STANDARD EQUIPMENT
HITCH/RECEIVER
2”
TOWING CAPACITY
1500 lbs.
WINCH
3500 lbs.
