ENGINE
Type: 3-cylinder, indirect-injection, Water-cooled
Model (Tier 4): MHI S3L2
Engine HP (Gross): 24.4
PTO HP: 17.1
Rated Speed (RPM): 2,500
Displacement (cu. in.): 80.4
Fuel Tank Capacity (gal): 7.4
Alternator: 12V - 50 Amps
DRIVE TRAIN
Transmission: Hydrostatic Drive
No. of Speeds: 3 Ranges
Brakes: Wet, Multi Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear PTO: Standard (540 rpm)
HYDRAULIC SYSTEM
Implement pump (gpm): 7.9
Steering pump (gpm): 4.6
Total flow (gpm): 12.5
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,808
Lift control type: Manual
DIMENSIONS
Overall length with 3pt (in): 118
Wheelbase (in): 66
Min. overall width with AG tires (in): 54
Height to top of ROPS with Ag tires (in): 88
TIRE SIZE
Ag Front/Rear: 7 - 14 / 11.2 - 24
IND Front / Rear 25 x 8.5 - 14 / 43 x 16 - 20
Turf Front / Rear 25 x 8.5 - 14 / 41 x 14 - 20
WEIGHT
Total weight without ballast (lbs.): 2,434
Attachments
LL3110
Quick Attach, Skid Steer Compatible Front End Loader with Grill Guard & 66” bucket
VIEW SPECS
More Options
Remote Valve- 1 pair (2 outlets) or 2 pair (4 outlets)
Detent Kit
Work Light
Horn
Front Weight – 44 lbs. x 4
