ENGINE
Type: 3Cylinder-IDI
Model (Tier 4): 3TNV80F-ZXKLST(YANMAR)
Engine HP (Gross): 24.7
PTO HP: 19.3
Rated Speed (RPM): 2,800
Displacement (cu. in.): 77.3
Fuel Tank Capacity (gal): 6.79
Alternator (V-A): 12-40
DRIVE TRAIN
Transmission: HST
No. of Speeds: 3 Ranges
Brakes: Wet, Multi Disc
Steering: Hydrostatic Power Steering
PTO
Type: Independent
Rear (rpm): 540
Mid PTO (option): 2,500
HYDRAULIC SYSTEM
Control System: Position
Implement pump (gpm): 5.6
Steering pump (gpm): 3.7
Total flow (gpm): 9.3
Category, 3 pt hitch: CAT 1
Hitch Lift capacity (lb): 1,896
Remote Valves: 1 PAIR (Option)
DIMENSION
Overall length, Frame to link, (in.): 111.9
Wheelbase (in.): 63.4
Overall width with tires, in. (in.): 48.7
Height to top of ROPS (in.): 86.4
TIRE SIZE
IND (Front/Rear): 23 x 8.5 – 12 / 12 – 16.5
Turf (Front/Rear): 22 x 8.5 – 12 / 31 x 15.5 – 15
Versa Turf (Front/Rear): 12 x 16.5/23 x 8.5
WEIGHT
Total weight without ballast (lbs.): 1,764
